Briskheat High Temperature Heating Cords (HWC1040)

Briskheat High Temperature Heating Cords (HWC1040)

Briskheat HTC Heating Cord

As low as $54.00

HTC Heating Cord

  • Heating cords designed for use on small tubes, vessels, or any application where space is limited.
  • Extremely flexible heating cords can be wrapped around objects as small as 1/8" (3mm) diameter.
  • Rapid thermal response provides accurate heat when you need it.
  • Multi-stranded resistance wire heating element provides exceptional flexibility and durability.
  • Fiberglass outer sheath provides electrical insulation for safe use with electrically conductive surfaces.
  • Available in a wide variety of length and width configurations.
  • Ideal for laboratory, R&D, gas tubing, production, maintenance, temporary heat, and more.
  • Safe for use with glass and electrically conductive metal surfaces.
  • Choice of power leads on same end or opposite ends to suit your electrical needs.
  • Includes 9" (230mm) long high temperature tie downs for safe and easy installation.
  • Temperature controller is required for safe operation of this product.
  • Built-in split-plug design easily connects to your choice of temperature controlling device.



Ordering Part Number:

Part Number

120 VAC

Part Number

240 VAC

Cord Length

ft (m)

Total

Watts

Lead Length

ft (m)

Standard

Price

HTC451007N/A0.5 (0.15)29.262500C
HTC451006N/A1 (0.3)29.262500C
HTC451005N/A2 (0.6)29.262500C
HTC451001N/A3 (0.9)29.262500C
HTC451008N/A4 (1.2)29.262500C
HTC451002HTC4520026 (1.8)23.512000C
HTC451009N/A8 (2.4)29.152000C
HTC451003HTC45200312 (3.7)29.262500C





BriskHeat
from BriskHeat



Only %1 left
SKU
HTC
Briskheat HTC Heating Cord is available to buy in increments of 1

HTC Heating Cord



Overview:
  • Heating cords designed for use on small tubes, vessels, or any application where space is limited.
  • Extremely flexible heating cords can be wrapped around objects as small as 1/8" (3mm) diameter.
  • Rapid thermal response provides accurate heat when you need it.
  • Multi-stranded resistance wire heating element provides exceptional flexibility and durability.
  • Fiberglass outer sheath provides electrical insulation for safe use with electrically conductive surfaces.
  • Available in a wide variety of length and width configurations.
  • Ideal for laboratory, R&D, gas tubing, production, maintenance, temporary heat, and more.
  • Safe for use with glass and electrically conductive metal surfaces.
  • Choice of power leads on same end or opposite ends to suit your electrical needs.
  • Includes 9" (230mm) long high temperature tie downs for safe and easy installation.
  • Temperature controller is required for safe operation of this product.
  • Built-in split-plug design easily connects to your choice of temperature controlling device.


Specifications:
  • Maximum exposure temperature: 900°F (482°C)
  • Diameter: 3/16” (4.8mm)
    • Construction:
      • HTC series: Double braided fiberglass outer sheath
      • HWC series: Double braided high temperature Samox® fiberglass outer sheath
    • Power density:
      • HTC series: 21 watts/ft (68 watts/m)
      • HWC series: 60 watts/ft (196 watts/m)
    • 24" (610mm) power leads with
      • 120VAC: Separable 2-prong split-plug (NEMA 1-15)
      • 240VAC: Crimped ferrule wire connection
  • Suitable for electrically conductive surfaces
    • 2 to 6ft (0.6 to 1.8m) long power leads with
      • 120VAC: separable molded plug
      • 240VAC: bare wire connection
  • Includes high-temperature tie-downs for easy installation

Accessories - X2 Digital PID Benchtop Temperature Controller

BriskHeat® X2 Benchtop PID Digital Temperature Controller is designed for general purpose use in indoor environments to control temperatures on applications requiring automatic control. The controller provides a simple three-key user control and a plug-and-play set-up.
  • Key User Features:
    • Compact, plug and play design: 6.39" W x 9.48"D x 1.99"H
    • Simple, three-key user control
    • Programmable temperature range: 32°F to 1400°F (0°C to 760°C)
      • Accuracy: Type-J +/- 0.9°F (0.50°C) Type-K +/- 0.5°F (0.25°C)
    • Programmable in either °C or °F
    • Auto / manual control ability
    • Advanced PID control
  • Alarm and Protection Features:
    • User programmable alarm types, including latching options
    • Programmable security lock levels
    • Fused input
    • Sensor break protection with average output options which allows process to continue heating
  • Sensor Input: Type J or K thermocouple
