Briskheat HTC Heating Cord with SDC Digital Temperature Controller (Special Bundle Price)

Briskheat HTC Heating Cord with SDC Digital Temperature Controller (Special Bundle Price)

BriskHeat Lower Hemispherical Heating Mantle with SDC Digital Temperature Controller K-Type Thermocouple

BriskHeat Lower Hemispherical Heating Mantle with SDC Digital Temperature Controller K-Type Thermocouple

Briskheat Lower Hemispherical Heating Mantle with SDC Digital Temperature Controller J-Type Thermocouple

As low as $474.00
Lower Hemispherical Heating Mantle with SDC Digital Temperature Controller (Special Bundle Price) J-Type Thermocouple
  • Special bundle price
  • Apply uniform heat to round-bottom flasks
  • Excellent alternative to other heating methods like a Bunsen burner
  • Ideal for use with a basket ring stand

Lower Hemispherical Heating Mantle

  • Uniform, low-watt density heating element
  • Maximum exposure temperature: 450°C (842°F)
  • Fiberglass cloth outer shell

SDC Benchtop Digital Temperature Controller

  • Compact, digital on / off temperature controller
  • Easy programming (°C or °F)
  • Temperature control range: 0- 600°C or 32-999°F
  • Compatible with a wide range of heaters and applications
  • 10 amp fused output
  • Includes built-in thermocouple (J Type)

Bundles include:

  1. Standard SDC Benchtop temperature controller (120VAC) with built-in 5' (1.5m) long J-Type or K-Type thermocouple sensor (see ordering information)
  2. Lower Hemispherical Heating Mantle

Note: Heater with different voltage, size, or wattage (Contact us for detailed quotation)



BriskHeat
from BriskHeat

Only %1 left
SKU
SDCJFA-HM
Briskheat Lower Hemispherical Heating Mantle with SDC Digital Temperature Controller J-Type Thermocouple is available to buy in increments of 1
Lower Hemispherical Heating Mantle with SDC Digital Temperature Controller (Special Bundle Price) J-Type Thermocouple
  • Special bundle price
  • Apply uniform heat to round-bottom flasks
  • Excellent alternative to other heating methods like a Bunsen burner
  • Ideal for use with a basket ring stand

Lower Hemispherical Heating Mantle

  • Uniform, low-watt density heating element
  • Maximum exposure temperature: 450°C (842°F)
  • Fiberglass cloth outer shell

SDC Benchtop Digital Temperature Controller

  • Compact, digital on / off temperature controller
  • Easy programming (°C or °F)
  • Temperature control range: 0- 600°C or 32-999°F
  • Compatible with a wide range of heaters and applications
  • 10 amp fused output
  • Includes built-in thermocouple (J Type)

Bundles include:

  1. Standard SDC Benchtop temperature controller (120VAC) with built-in 5' (1.5m) long J-Type or K-Type thermocouple sensor (see ordering information)
  2. Lower Hemispherical Heating Mantle

Note: Heater with different voltage, size, or wattage (Contact us for detailed quotation)



  • Fiberglass cloth outer shell
  • Uniform, low-watt density knitted and braided heating element. Temperatures up to 900oF (482oC).
  • Multi-stranded resistance wire for increased durability and flexibility
  • 120VAC model includes 3" (76mm) lead wire with NEMA L1-15R connector and a 4 foot (1.2m) power cord with NEMA 1-15 plug
  • 240VAC model includes 3" (76mm) lead wire with no plug
  • Temperature controller required

SDC Benchtop Digital Temperature Controller

  • Small Unit Size:
    • 5.5 in L x 4.25 in W x 1.75 in H
    • 140 mm L x 108 mm W x 45 mm H
  • On-Off control
  • Temperature Control Range: 32-999°F (°F models) or 0-700°C (°C models)
    • Accuracy: +/- 1% FS
  • Includes J-type or K-type thermocouple sensor
    • 5-foot (1.5 m) factory installed
  • 120 VAC or 240 VAC power input
  • Relay output rated for 10A @ 240VAC
  • Sensor break options
  • Upper and lower limits of the setpoint can be adjusted
  • Set-point value can be adjusted by using single key
  • Hysteresis adjustable between 1 and 99°F/°C
  • Exposure Temperature: 32-158°F (0-70°C)
    • 80% humidity non-condensing
  • 5-foot (1.5 m) input power cord
    • 120VAC unit = NEMA 5-15 plug
    • 240VAC unit = NEMA 6-15 plug
  • 5-foot (1.5 m) output power cord
    • 120VAC unit = NEMA 5-15R receptacle
    • 240VAC unit = NEMA 6-15R receptacle
  • Internal buzzer for alarm condition / error

* Other plug receptacle options available contact us for more information



BriskHeat
from BriskHeat

More Information
Manufacturer BriskHeat
Child Skus SDCJFA-HM0050-HS1,SDCJCA-HM0050-HS1,SDCJFA-HM0100-HS1,SDCJCA-HM0100-HS1,SDCJFA-HM0125-HS1,SDCJCA-HM0125-HS1,SDCJFA-HM0200-HS1,SDCJCA-HM0200-HS1,SDCJFA-HM0250-HS1,SDCJCA-HM0250-HS1,SDCJFA-HM0500-HS1,SDCJCA-HM0500-HS1,SDCJFA-HM1000-HS1,SDCJCA-HM1000-HS1,SDCJFA-HM2000-HS1,SDCJCA-HM2000-HS1,SDCJFA-HM3000-HS1,SDCJCA-HM3000-HS1,SDCJFA-HM5000-HS1,SDCJCA-HM5000-HS1
Part Number DHCS10A
Part Number FFSL1-6
