RTD Hook-Up Wire

For detailed specifications, see Product Features section below.

Part Number No. of Conductors AWG Insulation Type Max Temp Spool Length (ft) Price
EXTT3CU26S-100 3 26 Teflon® over each conductor/Twisted/Teflon® jacket overall, 1 Red, 2 Black 500°F 100 $114
EXTT3CU26S-500 3 26 Teflon® over each conductor/Twisted/Teflon® jacket overall, 1 Red, 2 Black 500°F 500 $325
EXTT3CU26S-1000 3 26 Teflon® over each conductor/Twisted/Teflon® jacket overall, 1 Red, 2 Black 500°F 1000 $650
EXTT4CU26S-100 4 26 Teflon® over each conductor/Twisted/Teflon® jacket overall, 1 Red, 2 Black 500°F 100 $123
EXTT4CU26S-500 4 26 Teflon® over each conductor/Twisted/Teflon® jacket overall, 1 Red, 2 Black 500°F 500 $350
EXTT4CU26S-1000 4 26 Teflon® over each conductor/Twisted/Teflon® jacket overall, 1 Red, 2 Black 500°F 1000 $700
RT3-24-8-705-100 3 24 Glass braid over each conductor/Twisted/Glass braid jacket overall 900°F 100 $60
RT3-24-8-705-500 3 24 Glass braid over each conductor/Twisted/Glass braid jacket overall 900°F 500 $240
RT3-24-8-705-1000 3 24 Glass braid over each conductor/Twisted/Glass braid jacket overall 900°F 1000 $480
RT3-22-4-701-100 3 22 PVC over each conductor/Twisted/PVC jacket overall  220°F 100 $42
RT3-22-4-701-500 3 22 PVC over each conductor/Twisted/PVC jacket overall  220°F 500 $170
RT3-22-4-701-1000 3 22 PVC over each conductor/Twisted/PVC jacket overall  220°F 1000 $340
RT3-22-8-704-100 3 22 FEP Teflon® over each conductor/Twisted/FEP Teflon® jacket overall 400°F 100 $85
RT3-22-8-704-500 3 22 FEP Teflon® over each conductor/Twisted/FEP Teflon® jacket overall 400°F 500 $380
RT3-22-8-704-1000 3 22 FEP Teflon® over each conductor/Twisted/FEP Teflon® jacket overall 400°F 1000 $760


Lead Time

EXTT3CU26S and EXTT4CU26S Spools: In Stock

RT3-24-8-705, RT3-22-4-701, and RT3-22-8-704 Spools: 5 Business Days from Date of Approved Order

For expedited service, please contact Sales Department at (510) 606-1012



As low as $42.00
RTD Hook-Up Wire is available to buy in increments of 1

RTD Hook-Up Wire Conductor Wire Parameters

Conductor Wire Size Diameter Diameter (mm)
14 0.064 1.630
16 0.051 1.290
18 0.040 1.020
20 0.032 0.812
22 0.025 0.644
24 0.020 0.511
26 0.016 0.405
28 0.013 0.321
30 0.010 0.255
32 0.008 0.202
34 0.006 0.160
36 0.005 0.127
